View and Download Panasonic UF-8000 service handbook online. UF-8000 Fax Machine pdf manual download. Also for: Uf-7000, Uf-8100, Uf-7100. Fax Machine Panasonic Panafax UF-885 User Manual. Panasonic facsimile user's guide (184 pages).

Panasonic Updated: 2007-06-30

From a one-page fax, up to large, multi-page transmissions, the Panafax UF-8000 is designed to handle all of your business needs. Supported by a fast 0.7-second Quick Scan, the UF-8000's large capacity 100-page Auto Document Feeder easily manages big or small jobs, while improving your document handling by minimizing the risk of double-feeding, pickup failures and skewing.

With 80 one-touch stations at your fingertips, faxing your documents is as easy as a push of a button. The UF-8000's versatile, one-touch Auto-Dialer is super easy to program and search for stored numbers and email addresses. Best of all, the UF-8000 is built to last and designed to grow with you as your business needs expand. And upgrades such as Network Scanning, Scan-to-Email/PC and LAN PC Faxing, ensure that UF-8000 is the right choice for your business needs today and tomorrow.

• Super high-speed scanning of 0.7 seconds per page
• 100-sheet standard Automatic Document Feeder (ADF)
• 33.6 Fax with JBIG
• Standard Duplex printing / Copying / Fax, enabling the printing of 500 images
• 250 sheet cassette expandable to 800 sheets
• Network printing up to 19ppm
• 12MB standard memory (new SD type memory cards up to 512MB capacity)
• USB port standard
• QWERTY keyboard
• Optional Internet Fax / Email / Network Scanner kit
• Optional 2nd G3 communication port (Dual line fax)
• Document Management System software included
• 280 Auto-dialers expandable to 1,000 with optional SD memory card

Panasonic Panafax Uf-8000 User Manual

General Functions:
ADF Capacity 100 Sheets
Recording Paper Capacity 250
Maximum Paper Capacity 800
Power Requirements AC 120V, 50/60 Hz
Power Consumption Max: Approximately 1000 W Power
Save Mode: 12 Wh
Sleep Mode: 7 Wh
Dimensions
Dimensions and weight are approximate 17.7' (W) x 16.5' (D) x 17.6' (H)
Weight Approximately 48.5 lbs
Bypass Tray Yes
Accounting Software Compatible Yes
Document Size Max: 8.5' x 78.7' with operators assistance 1
Min: 5.5' x 5.5'
Network Scanner Functions:
Network Scanner Interface 10/100 Ethernet
Scanning Resolution Standard: 203 dpi x 98 dpi
Fine: 203 dpi x 196 lpi
Super Fine: 406 dpi x 391 lpi
600 dpi: 600 dpi x 600 dpi
Scanning Speed Approximately 1.1 seconds (150 x 150 dpi)
Network Printer Functions:
Local Printer Interface USB1.1
Printer Language Standard: Panasonic Printing System for Windows®
Option: PCL 5e Emulation, PCL 6 Emulations
Paper Size Letter/ Legal/ Invoice/ Envelope (# 9, # 10) 2
Printer Memory 32MB
Compatible Operating System Windows XP/2000/Server 2003/98/Me, Windows NT 4.0
Mac OS 8.6 - 10.3 (PS only)
Printing Resolution 1200 dpi equivalent 3 x 600 dpi
Network Printer Interface 10/100 Ethernet
G3 Fax Functions:
G3 Fax Compatibility ITU-T Group 3, ECM
Modem Speed 33,600 - 2,400 bps with automatic fallback
G3 Fax Transmission Speed 4 Approximately 2.7 seconds per page (letter size)
G3 Fax Scanning Resolution Standard: 203 dpi x 98 lpi (8 dots/mm x 3.85 lines/mm)
Fine: 203 dpi x 196 lpi (16 dots/mm x 15.4 lines/mm)
Super Fine: 406 dpi x 391 lpi (16 dots/mm x 15.4 lines/mm)
600 pdi: 600 x 600 dpi
No. of Auto Dialers Standard: 280
Max: 1,000 with optional SD memory card (32MB to 512MB)
Coding Scheme MH/MR/MMR/JBIG
Number of Memory Job Files 50
Effective Scanning Width 8.34'
Automatic Document Feeder 100 Sheets
Scanning Speed 5 Approximately 0.7 seconds per page (letter)
Recording method Monochrome laser printing on plain paper
Recording Paper Size Letter / Legal
Effective Recording Width 8.15'
Paper Feed Standard Tray: 250 sheets paper tray x 1 + 1-sheet bypass
Maximum: 800 sheet with optional paper tray
Image Memory Capacity 6 Standard: 12 MB (720 pages)
Max: 512 MB (12,750 pages) with optional SD Memory card
Scan-to-Email / Internet Fax Functions:
Scan-to-Email Compatibility IETF RFC 2305, ITU-T T.37
Communication Protocol TCP/IP, SMTP, POP3, MIME, DHCP, LDAP, SNMP/MIB
Network Connectivity 10/100 Ethernet
Data Format TIFF-FX (Profile S/FJ), PDF
