  1. Blueline 8ch Camera Dvr User Manual 2017

User Manual of Car DVR GC- K6000 Product Description Product structure 1) up select button 2) menu button 3) select the button down 4) USB data interface 5) bracket mounting holes 6) HDMI output 7) Power switch 8) TF card slot 9) the HOLD button 10) the mode selection button 11) OK to confirm button. View and Download Defender SN301-8CH instruction manual online. 8 Channel H.264 Smart DVR Security System w/ Coaching iMenu and 8 Outdoor Night Vision Surveillance Cameras. 8CH H.264 DVR Security System with 8 Indoor/Outdoor Night Vision Surveillance Cameras. This CCTV video surveillance System is a complete DVR security system that has all the latest features, yet is very easy to use. This kit includes a four channel DVR with eight indoor/outdoor night vision cameras, video cables and power adaptor.

Regular Price:$359.99 USD

Special Price$90.99 USD

Support

  • How can we help?

Overview

8 Cameras, 8 Channels
Protect yourself against any outside forces that may threaten the safety of your home or business with the Defender BlueLine security series. This 8 channel DVR kit comes with 8 ultra high resolution cameras, packed with all the valuable features you need to neutralise any threat and keep your peace of mind at an all-time high.
See It All – Day or Night
See it all in pristine detail, day or night: ultra high resolution 600 TVL cameras with 75ft night vision leave nothing to the imagination.
500GB Hard Drive
Record more than 2 years of footage for quick and easy playback anytime, anywhere.
Smartphone Viewing in 1 Step
Defender’s free 1 Step Remote Viewing software instantly networks your DVR with the Internet. View your video feeds live, receive instant email alerts and watch any previously recorded footage from anywhere in the world with an Internet connection on your smartphone, tablet or computer.
Weather the Elements
Defender cameras’ IP65-rated anodized aluminum housing means your system will remain active through all types of weather conditions.
True Do-It-Yourself Security
Defender BlueLine gives you all the peace of mind of a professionally installed system with the satisfaction that comes from knowing you did it all yourself. Don’t leave the safety of your property to chance – trust Defender to help you protect what you value most.
What's Included:
DVR with 500GB HDD, 8 x 600TVL security cameras, 8 x 60ft security extension cable, 2x BNC to RCA connectors, 10ft RJ-45 ethernet cable, 6ft power adapter (cUL certified), 6ft RCA video cable, USB mouse, IR remote controller (batteries not included), quick start guide, instruction manual & software CD.

Specifications

FunctionalityPentaplex
Video CompressionH.264
Audio CompressionG.726/ADPCM-IMA
Video Input8 x BNC
Video Output1 x BNC, 1 x VGA
Audio Input4 x RCA
Audio Output1 x BNC
USB Port2
Resolution800×600、1024×768、1280×1024、1440×900
Recording Total Frame RateNTSC: 240 fps @ CIF / PAL: 200 fps @ CIF NTSC : D1(704 X 480), HD1(704 X 240), CIF(352 X 240) / PAL: D1(704 X 576)
Recording Frame Rate Per Channel30 FPSv
Recording Resolution Selectable: NTSC: D1(704 x 480); HD1(704 x 240); CIF (352 x 240) / PAL: D1(704 x 576); HD1(704 x 288); CIF (352 x 288)
Recording ModesContinuous / Time Schedule / Motion Detection
Recording MediaHDD (Backup via USB)
Storage CapacityMax 2TB, 1HDD
HDD TypeSATA 3.5'
HDD Size2 TB
Video FormatNTSC/PAL
Video Loss AlarmAuto Detect Alarm
Live Frame Rate30 FPS
Live ViewingFull/ 1/4
Picture-in-PictureNO
Network ProtocolTCP/IP, PPPoE, DHCP and DDNS
Network LAN IPStatic, Dynamic
Network ConnectionRJ45, 10M/100M
Supported Operating SystemsWindows XP, Windows Vista, Windows 7
BrowsersInternet Explorer& LAN
Back-upFlash drive/USB HDD/USB DVD-RW/Network download
Play Search ModeTime/Date
Play SpeedNormal Play /Fast Forward /Fast Rewind/ Frame by Frame
Pan/Tilt/ZoomRS-485(PTZ Control)
OSD Language DisplayMulti-Language
Time and Date Stamp DisplayYes
Password ProtectionYes, Menu Password
Operating SystemLinux 2.6 O/S
ProcessorARM 9
Disk Full WarningYes
Automatic Overwrite OptionYes
Housing MaterialAluminum
Housing ColorBlack/Silver
Power Input12V DC 3A
Power Consumption<12W(Without hard disks)
Power Adapter Input100V 50/60HZ~240V 50/60HZ
Operating Temperature32 °F~+122°F
Dimensions11.4in (W) x 8.1in (D) x 1.65in (H)
Number of Channels8
Image Sensor1/3' CMOS
Image Resolution600 TVL
Outdoor Useyes
IP RatingIP65
Focal Length6mm
Focus TypeFixed
Optimal Focal Distance20 ft.
Night VisionYes
Night Vision Distance100ft
LEDs36
IR LED Control Automatic (CDS Sensor)
IR Wave Length850nm
Video OutputBNC/DC
TV SystemNTSC
Viewing Angle60 Degrees
Electronic Shutter (Sec)1/60 ~ 1/100000 sec
Signal/Noise Ratio>48dB
Camera BracketYES
Min. Illumination0 lux
AGCAutomatic
ELCAutomatic
Gamma Correction>0.45
While BalanceON
Sun SheildYES
IR Cut Filteryes
UPC061783254660
What's Included
  • DVR with 500GB HDD
  • 8 x 600TVL Security Cameras
  • 8 x 60ft Security Extension Cable
  • 2x BNC to RCA Connectors
  • 10ft RJ-45 Ethernet Cable
  • 6ft Power Adapter (cUL certified)
  • 6ft RCA video cable
  • USB Mouse
  • IR Remote Controller (batteries not included)
  • Quick Start Guide
  • Instruction Manual & Software CD
